25.6V 100Ah LiFePO4 UPS battery pack
HG8AE4931
25.6V 100Ah LiFePO4 UPS battery pack
Model: HG8AE4931
Voltage: 25.6V
Capacity: 100Ah
Structure: 8S1P
Application field: UPS,Energy Storage Equipment
Model: HG8AE4931
Voltage: 25.6V
Capacity: 100Ah
Structure: 8S1P
Application field: UPS,Energy Storage Equipment
Quantity
| Description: | 25.6V 100Ah LiFePO4 UPS battery pack |
| Product No.: | HG8AE4831 |
| Cell model: | LiFePO4 100Ah/3.2V |
| Battery Specification: | 8S1P/100Ah/25.6V |
| Nominal voltage: | 25.6V |
| Nominal capacity: | 100Ah |
| Charging voltage: | 28.8V |
| Charging current: | 50A |
| Discharge current: | 50A |
| Maximum discharge current: | 200A |
| Discharge cut-off voltage: | 20V |
| Internal resistance : | ≤10mΩ |
| Delivery voltage: | 24-26V |
| Battery weight: | 20kg |
| Product size: | 376*222*130mm(max) |
| Operating temperature: | Charging temperature: 0-45°C; Discharge temperature: -20-60°C |
| Storage temperature environment: | 1 month -5-45°C; 3 months -5-35°C; 12 months -5-30°C. |
| Relative humidity: | 65 ± 20% |
| Battery structure: | plastic shell |
| Lithium Battery protection: | short circuit protection, overcharge protection, over discharge protection, over current protection, Power management，etc. |
| Application field: | UPS,Energy Storage Equipment |
